User interface, Debug interface, Expansion slot – Rainbow Electronics SBC35-A9G20-C11 User Manual
Page 12: Section 4, Configuration, Solder pads & switch configuration
1x Ethernet 100-base TX with three status LED
1.7. User Interface
1x user orange led (LD1)
1x user input pushbutton (SW1)
1.8. Debug Interface
20-pin HE10-2x5 JTAG/ICE interface connector
HE10-2x5 DBGU COM Port
1.9. Expansion slot
1x SD/MMC card slot
1x Compact Flash card slot
2x Expansion connectors.
These two expansion connectors allow the developer to extend the features of the board by
adding external hardware components or boards.
S
ECTION
4
1. Configuration
1.1. Solder pads & switch configuration
Datasheet USG-00019-A01
12/24
