MAX9610
1µA, µDFN/SC70, Lithium-Ion Battery,
Precision Current-Sense Amplifier
8 _______________________________________________________________________________________
Chip Information
PROCESS: BiCMOS
1 2 3
6 5 4
RS+ RS- N.C.
GND OUT N.C.
MAX9610T/F/H
1mm x 1.5mm μDFN
TOP VIEW
(PINS ON BOTTOM)
GND
RS-
OUT
1
5
RS+
GND
MAX9610T/F/H
2mm x 2.2mm SC70
TOP VIEW
2 3
4
(DIAGRAMS NOT TO SCALE.)
+
+
Pin Configurations
