MAX9610
1µA, µDFN/SC70, Lithium-Ion Battery,
Precision Current-Sense Amplifier
_______________________________________________________________________________________
3
PARAMETER
SYMBOL
CONDITIONS
MIN
TYP
MAX
UNITS
V
SENSE
= 50mV, G = 25
170
V
SENSE
= 50mV, G = 50
110
Small-Signal Bandwidth
BW
V
SENSE
= 50mV, G = 100
60
kHz
Output Settling Time
t
S
1% final value, V
SENSE
= 25mV
35
μs
Power-Up Time
t
ON
1% final value, V
SENSE
= 25mV
100
μs
ELECTRICAL CHARACTERISTICS (continued)
(V
RS+
= V
RS-
= 3.6V, V
SENSE
= (V
RS+
- V
RS-
) = 0, T
A
= -40°C to +85°C, unless otherwise noted. Typical values are at T
A
= +25°C.)
(Note 1)
Note 1: All devices are 100% production tested at T
A
= +25°C. All temperature limits are guaranteed by design.
Note 2: V
OUT
= 0V. I
CC
is the total current into RS+ plus RS-.
Note 3: V
OS
is extrapolated from measurements for the Gain Error test.
Note 4: Gain Error is calculated by applying two values of V
SENSE
and calculating the error of the slope, vs. the ideal:
G = 25: V
SENSE
20mV and 120mV
G = 50: V
SENSE
10mV and 60mV
G = 100: V
SENSE
5mV and 30mV
Note 5: The device is stable for any external capacitance value.
Note 6: V
OH
is the voltage from V
RS-
to V
OUT
with V
SENSE
= 3.6V/Gain.
Typical Operating Characteristics
(V
RS+
= V
RS-
= 3.6V, T
A
= +25°C.)
20
15
10
5
0
-250 -200-150-100 -50
0
250
200
150
100
50
MAX9610F
OFFSET VOLTAGE HISTOGRAM
MAX9610 toc01
OFFSET VOLTAGE (
μV)
N (%)
30
25
20
15
10
5
0
-0.2 -0.15 -0.1 -0.05
0
0.2
0.15
0.1
0.05
MAX9610F
GAIN ACCURACY HISTOGRAM
MAX9610 toc02
GAIN ACCURACY (%)
N (%)
0
300
200
100
400
500
600
700
800
900
1000
-40
10
-15
35
60
85
SUPPLY CURRENT
vs. TEMPERATURE
MAX9610 toc03
TEMPERATURE (
°C)
SUPPLY CURRENT (nA)
5.5V
3.6V
1.6V
