MAX9610
1µA, µDFN/SC70, Lithium-Ion Battery,
Precision Current-Sense Amplifier
_______________________________________________________________________________________ 5
Typical Operating Characteristics (continued)
(V RS+ = V RS- = 3.6V, T A = +25°C.)
10 μs/div
LARGE-SIGNAL RESPONSE
G = 50
50mV/div
1V/div
MAX9610 toc17
V SENSE
V OUT
10 μs/div
LARGE-SIGNAL RESPONSE
G = 100
20mV/div
1V/div
MAX9610 toc18
V SENSE
V OUT
10 μs/div
SMALL-SIGNAL RESPONSE
G = 100
5mV/div
200mV/div
MAX9610 toc15
V SENSE
V
OUT
10 μs/div
LARGE-SIGNAL RESPONSE
G = 25
100mV/div
1V/div
MAX9610 toc16
V SENSE
V OUT
10 μs/div
SMALL-SIGNAL RESPONSE
G = 25
20mV/div
200mV/div
MAX9610 toc13
V SENSE
V
OUT
10 μs/div
SMALL-SIGNAL RESPONSE
G = 50
10mV/div
200mV/div
MAX9610 toc14
V SENSE
V OUT
