MAX4036–MAX4039
Low I
BIAS
, +1.4V/800nA, Rail-to-Rail Op Amps
with +1.2V Buffered Reference
_______________________________________________________________________________________ 9
REFERENCE LOAD-TRANSIENT RESPONSE
(SINKING CURRENT)
MAX4036 toc32
2.5ms/div
0
V
REF
500mV/div
0
2µA
I REF
MAX4036 toc33
2.5ms/div
0
0
20µA
I REF
V REF
500mV/div
REFERENCE LOAD-TRANSIENT RESPONSE
(SINKING CURRENT)
REFERENCE LOAD-TRANSIENT RESPONSE
(SOURCING CURRENT)
MAX4036 toc34
1ms/div
0
0
I REF
10µA
V REF
500mV/div
MAX4036 toc35
1ms/div
0
0
I REF
100µA
V REF
500mV/div
REFERENCE LOAD-TRANSIENT RESPONSE
(SOURCING CURRENT)
REFERENCE TURN-ON
TRANSIENT RESPONSE
MAX4036 toc36
1ms/div
V DD
0V
3V
0V
V REF
0.1Hz TO 10Hz REFERENCE NOISE
MAX4036 toc37
1s/div
20µV/div
Typical Operating Characteristics (continued)
(V DD = 3V, V SS = V CM = 0V, R L to V DD /2, T A = +25°C, unless otherwise noted.)
