MAX16841
Controller IC for Dimmable Offline LED Lamps
IN to GND ..............................................................-0.3V to +26V
NDRV, DIMOUT to GND ........................... -0.3V to (VIN + 0.3V)
All Other Pins to GND .............................................-0.3V to +6V
NDRV Continuous Current .............................................. Q10mA
DIMOUT Continuous Current ............................................ Q2mA
Continuous Power Dissipation (TA = +70NC)
8 SO (derate 7mW/NC above +70NC) ..................588.2mW
Operating Temperature Range ........................ -40NC to +125NC
Junction Temperature .....................................................+150NC
Storage Temperature Range ............................ -65NC to +150NC
Lead Temperature (soldering, 10s) ................................+300NC
Soldering Temperature (reflow) ......................................+260NC
8 SO
Junction-to-Ambient Thermal
Resistance (B
JA
) (based on S8+2) ...........................136NC/W
Junction-to-Case Thermal
Resistance (B
JC
) (based on S8+2) .............................38NC/W
ABSOLUTE MAXIMUM RATINGS
Note 1: Package thermal resistances were obtained using the method described in JEDEC specification JESD51-7, using a four-
layer board. For detailed information on package thermal considerations, refer to www.maxim-ic.com/thermal-tutorial .
Stresses beyond those listed under “Absolute Maximum Ratings” may cause permanent damage to the device. These are stress ratings only, and functional opera-
tion of the device at these or any other conditions beyond those indicated in the operational sections of the specifications is not implied. Exposure to absolute
maximum rating conditions for extended periods may affect device reliability.
PACKAGE THERMAL CHARACTERISTICS (Note 1)
ELECTRICAL CHARACTERISTICS
(V
IN
= 12V, T
A
= T
J
= -40NC to +125NC, unless otherwise noted. Typical values are at T
A
= +25NC.) (Note 2)
PARAMETER SYMBOL CONDITIONS MIN TYP MAX UNITS
IN Operating Range V
IN
11 20 V
IN Undervoltage Threshold UVLOR
IN
V
IN
rising, V
HYST
= 1V 9.5 10 10.5 V
IN Overvoltage Threshold OVLOR
IN
V
IN
rising, V
HYST
= 1.8V 21 22 23 V
IN Input Supply Current I
IN
NDRV not switching, V
TH
= 0V 0.7 1.3 2.6
mA
NDRV switching, 177.5k W/330pF on
NDRV, V
TH
= 5V, V
COMP
= 2V,
V
CS
= 0V, V
REFI
= 2.35V
1.7 2.7 4.2
V
IN
= 8V 1.6
TH
TH Operating Range
0 4 V
TH Threshold Voltage V
TH
V
TH
rising, hysteresis = 150mV 1.17 1.215 1.26 V
TH Input Supply Current V
TH
= 0V 0.16 0.3 F A
REFI
REFI Operating Range
V
REFI
0.5 3.25 V
REFI Input Supply Current V
REFI
= 2V 48.5 50 51.5 F A
DIMOUT
DIMOUT On-Resistance
DIMOUT = IN 20 40
I
DIMOUT = GND 20 40
TH to DIMOUT Propagation
Delay
V
TH
rising 40 80
ns
V
TH
falling 40 80
INTERNAL OSCILLATOR
Oscillator Frequency
RT = 47.5KI 50
kHz RT = 177.5kI 160 180 200
RT = 297.5kI 270 300 330
