MAX5070/MAX5071

High-Performance, Single-Ended, Current-Mode
PWM Controllers

20

______________________________________________________________________________________

Chip Information

TRANSISTOR COUNT: 1987

PROCESS: BiCMOS

Ordering Information (continued)

PART

TEMP RANGE

PIN-PACKAGE

MAX5071

AASA*

-40°C to +125°C

8 SO

MAX5071AAUA*

-40°C to +125°C

8 µMAX

MAX5071BASA

-40°C to +125°C

8 SO

MAX5071BAUA

-40°C to +125°C

8 µMAX

MAX5071CASA

-40°C to +125°C

8 SO

MAX5071CAUA

-40°C to +125°C

8 µMAX

OUT

GND

R

T

/C

T

1

2

8

7

VREF

V

CC

SYNC

CS

COMP

µ

MAX/SO

TOP VIEW

3

4

6

5

MAX5071A
MAX5071B

OUT

GND

R

T

/C

T

1

2

8

7

VREF

V

CC

ADV_CLK

CS

COMP

µ

MAX/SO

3

4

6

5

MAX5071C

Pin Configurations (continued)

Selector Guide

PART

FEEDBACK/

ADVANCED CLOCK

MAXIMUM DUTY

CYCLE (%)

PIN-PACKAGE

PIN COMPATIBLE

MAX5070AASA

Feedback

100

8 SO

UC2842/UCC2842

MAX5070AAUA

Feedback

100

8 µMAX

UC2842/UCC2842

MAX5070BASA

Feedback

50

8 SO

UC2844/UCC2844

MAX5070BAUA

Feedback

50

8 µMAX

UC2844/UCC2844

MAX5071AASA

Sync.

100

8 SO

MAX5071AAUA

Sync.

100

8 µMAX

MAX5071BASA

Sync.

50

8 SO

MAX5071BAUA

Sync.

50

8 µMAX

MAX5071CASA

ADV_CLK

50

8 SO

MAX5071CAUA

ADV_CLK

50

8 µMAX

*Future product—contact factory for availability.
