MAX5070/MAX5071
High-Performance, Single-Ended, Current-Mode
PWM Controllers
18 ______________________________________________________________________________________
Typical Application Circuits (continued)
MAX5071C
V CC
GND
COMP
R T /C T
VREF
CS
OUT
R T
C
T
V IN
ADV_CLK
C ST
R ST
0.5V/µs PULSE TRANSFORMER
MAX5078
V D
QR
N
N
N
QS
V OUT
V D
R CS
Figure 8. MAX5071C Typical Application Circuit (Isolated Forward with Secondary-Side Synchronous Rectification)
