MAX6652
Temperature Sensor and System Monitor
in a 10-Pin µMAX
2
_______________________________________________________________________________________
ELECTRICAL CHARACTERISTICS
(T
A
= -40°C to +125°C, unless otherwise noted. Typical values are at V
CC
= +5V, T
A
= +25°C.)
Stresses beyond those listed under “Absolute Maximum Ratings” may cause permanent damage to the device. These are stress ratings only, and functional
operation of the device at these or any other conditions beyond those indicated in the operational sections of the specifications is not implied. Exposure to
absolute maximum rating conditions for extended periods may affect device reliability.
V
CC
........................................................................-0.3V to +6.0V
Voltage on 12V
IN
...................................................-0.3V to +16V
All Other Pins ........................................................-0.3V to +6.0V
Output Current (SDA,
ALERT) ............................-1mA to +50mA
Junction Temperature .....................................................+150°C
Operating Temperature Range ........................-40°C to +125°C
Storage Temperature Range ............................-65°C to +150°C
Continuous Power Dissipation (T
A
= +70°C)
10-Pin µMAX (derate 5.6mW/°C above +70°C) ..........444mW
Lead Temperature (soldering, 10s) ................................+300°C
PARAMETER
SYMBOL
CONDITIONS
MIN
TYP
MAX
UNITS
POWER SUPPLY
Supply Voltage
V
CC
2.7
5.5
V
I
CC
Active
200
500
µA
Supply Current
I
SD
Shutdown mode, all digital inputs are
grounded
<1
10
µA
Power-On Reset Voltage
V
CC
_ rising or falling edge
2
V
TEMPERATURE
T
A
= +25°C
±2
-20°C
≤ T
A
≤ +80°C
±3
°C
Accuracy (Note 5)
V
CC
= +5V
-40°C
≤ T
A
≤ +125°C
±5
PSRR
V
CC
= +2.7V to +5.5V
0.7
1.3
°C/V
Resolution
±1
°C
ADC CHARACTERISTICS
Total Unadjusted Error
TUE
V
IN
> 10LSB
±1
±1.5
%
Differential Nonlinearity
DNL
V
IN
> 10LSB
±1
LSB
Supply Sensitivity
PSS
V
CC
= +2.7V to +5.5V
±1
V
Input Resistance
R
IN
12V
IN
, 2.5V
IN
, 3.3V
IN
100
150
200
k
Ω
Total Monitoring Cycle Time
tc
(Note 1)
200
300
ms
SCL, SDA, ADD
Logic Input Low Voltage
V
IL
0.8
V
V
CC
≤ 3.6V
2.0
V
Logic Input High Voltage
V
IH
V
CC
> 3.6V
2.6
V
SDA Output Low Voltage
V
OL
I
SINK
= 3mA
400
mV
Input Leakage Current
I
LEAK
V
IN
= 0 or 5V
±1
µA
ALERT
I
SINK
= 1.2mA, V
CC
> 2.7V
0.3
V
Output Low Voltage
V
OLA
I
SINK
= 3.2mA, V
CC
> 4.5V
0.4
V
TIMING
Serial Clock Frequency
f
SCL
0
400
kHz
Bus Free Time Between STOP and
START
t
BUF
1.3
µs
ABSOLUTE MAXIMUM RATINGS
All Voltages Are Referenced to GND
