Page 5
MAX9634
1µA, 4-Bump UCSP/SOT23,
Precision Current-Sense Amplifier
_______________________________________________________________________________________
5
SMALL-SIGNAL PULSE RESPONSE
(GAIN = 100)
MAX9634 toc13a
20
µs/div
V
OUT
V
SENSE
1V
1.5V
10mV
15mV
SMALL-SIGNAL PULSE RESPONSE
(GAIN = 50)
MAX9634 toc13b
25
µs/div
V
OUT
V
SENSE
1V
1.5V
20mV
30mV
SMALL-SIGNAL PULSE RESPONSE
(GAIN = 25)
MAX9634 toc13c
25
µs/div
V
OUT
V
SENSE
1V
1.5V
40mV
60mV
LARGE-SIGNAL PULSE RESPONSE
(GAIN = 100)
MAX9634 toc14a
20
µs/div
V
OUT
V
SENSE
1V
3V
10mV
30mV
LARGE-SIGNAL PULSE RESPONSE
(GAIN = 50)
MAX9634 toc14b
25
µs/div
V
OUT
V
SENSE
0.5V
3V
10mV
60mV
LARGE-SIGNAL PULSE RESPONSE
(GAIN = 25)
MAX9634 toc14c
25
µs/div
V
OUT
V
SENSE
0.5V
3V
20mV
120mV
Typical Operating Characteristics (continued)
(V
RS+
= V
RS-
= 3.6V, T
A
= +25°C, unless otherwise noted.)
Pin Description
PIN
UCSP
SOT23
NAME
FUNCTION
A1
5
RS+
External Sense Resistor Power-Side Connection
A2
4
RS-
External Sense Resistor Load-Side Connection
B1
1, 2
GND
Ground
B2
3
OUT
Output Voltage. V
OUT
is proportional to V
SENSE
= V
RS+
- V
RS-
.
