Absolute Maximum Ratings
(Notes 1 3)
If Military Aerospace specified devices are required
please contact the National Semiconductor Sales
Office Distributors for availability and specifications
Supply Voltage (V
CC
) 6 5V
Voltage at Inputs and Outputs b 0 3V to V
CC a 0 3V
Input Current at Any Pin (Note 4) g 5 mA
Package Input Current (Note 4) g 20 mA
Power Dissipation at T
A e 25 C (Note 5) 800 mW
ESD Susceptibility (Note 6) 1500V
Soldering Information
N Package (10 sec ) 260 C
SO Package
Vapor Phase (60 sec ) 215 C
Infrared (15 sec ) (Note 7) 220 C
Storage Temperature b 65 C to a150 C
Operating Ratings
(Notes 2 3)
Temperature Range T
MIN s T
A s T
MAX
ADC08031BIN ADC08031CIN b 40 C s T A s a 85 C
ADC08032BIN ADC08032CIN
ADC08034BIN ADC08034CIN
ADC08038BIN ADC08038CIN
ADC08031BIWM ADC08032BIWM
ADC08034BIWM ADC08038BIWM
ADC08031CIWM ADC08032CIWM
ADC08034CIWM ADC08038CIWM
Supply Voltage (V
CC
) 4 5 V
DC
to 6 3 V
DC
Electrical Characteristics
The following specifications apply for V
CC e V
REF e a 5 V
DC
and f
CLK e 1 MHz unless otherwise specified Boldface limits
apply for T A e T J e T MIN to T MAX
all other limits T
A e T
J e 25 C
ADC08031 ADC08032
ADC08034 and
ADC08038 with BIN
Units
Symbol Parameter Conditions CIN BIWM or
(Limits)
CIWM Suffixes
Typical Limits
(Note 8) (Note 9)
CONVERTER AND MULTIPLEXER CHARACTERISTICS
Total Unadjusted Error (Note 10)
BIN BIWM g LSB (max)
CIN CIWM g 1 LSB (max)
Differential
8 Bits (min)
Linearity
R REF Reference Input Resistance (Note 11) 3 5 kX
1 3 kX (min)
6 0 kX (max)
V
IN
Analog Input Voltage (Note 12) (V
CC a 0 05) V (max)
(GND b 0 05) V (min)
DC Common-Mode Error g LSB (max)
Power Supply Sensitivity V
CC e 5V g 5%
g LSB (max)
V
REF e 4 75V
On Channel Leakage On Channel e 5V 0 2
m A (max)
Current (Note 13) Off Channel e 0V 1
On Channel e 0V b 0 2
m A (max)
Off Channel e 5V b 1
Off Channel Leakage On Channel e 5V b 0 2
m A (max)
Current (Note 13) Off Channel e 0V b 1
On Channel e 0V 0 2
m A (max)
Off Channel e 5V 1
3
