Functional Description
(Continued)
4 0 THE ANALOG INPUTS
The most important feature of these converters is that they
can be located right at the analog signal source and through
just a few wires can communicate with a controlling proces-
sor with a highly noise immune serial bit stream This in itself
greatly minimizes circuitry to maintain analog signal accura-
cy which otherwise is most susceptible to noise pickup
However a few words are in order with regard to the analog
inputs should the input be noisy to begin with or possibly
riding on a large common-mode voltage
The differential input of these converters actually reduces
the effects of common-mode input noise a signal common
to both selected ‘‘a’’ and ‘‘b’’ inputs for a conversion
(60 Hz is most typical) The time interval between sampling
the ‘‘a’’ input and then the ‘‘b’’ input is
of a clock peri-
od The change in the common-mode voltage during this
short time interval can cause conversion errors For a sinus-
oidal common-mode signal this error is
V error (max) e V PEAK (2 q f CM )
0 5
f CLK
J
where f CM is the frequency of the common-mode signal
V
PEAK
is its peak voltage value
and f CLK is the A D clock frequency
For a 60Hz common-mode signal to generate a LSB er-
ror ( 5mV) with the converter running at 250kHz its peak
value would have to be 6 63V which would be larger than
allowed as it exceeds the maximum analog input limits
Source resistance limitation is important with regard to the
DC leakage currents of the input multiplexer Bypass capac-
itors should not be used if the source resistance is greater
than 1kX The worst-case leakage current of
g 1mA over
temperature will create a 1mV input error with a 1kX source
resistance An op amp RC active low pass filter can provide
both impedance buffering and noise filtering should a high
impedance signal source be required
5 0 OPTIONAL ADJUSTMENTS
5 1 Zero Error
The zero of the A D does not require adjustment If the
minimum analog input voltage value V
IN(MIN)
is not ground
a zero offset can be done The converter can be made to
output 0000 0000 digital code for this minimum input voltage
by biasing any V
IN (b) input at this V IN(MIN) value This
utilizes the differential mode operation of the A D
The zero error of the A D converter relates to the location
of the first riser of the transfer function and can be mea-
sured by grounding the V
IN (b) input and applying a small
magnitude positive voltage to the V
IN
(a) input Zero error
is the difference between the actual DC input voltage which
is necessary to just cause an output digital code transition
from 0000 0000 to 0000 0001 and the ideal
LSB value
( LSB e 9 8mV for V REF e 5 000V DC )
5 2 Full Scale
The full-scale adjustment can be made by applying a differ-
ential input voltage which is 1
LSB down from the desired
analog full-scale voltage range and then adjusting the mag-
nitude of the V
REF
IN input (or V
CC
for the ADC08032) for a
digital output code which is just changing from 1111 1110 to
1111 1111
5 3 Adjusting for an Arbitrary Analog Input
Voltage Range
If the analog zero voltage of the A D is shifted away from
ground (for example to accommodate an analog input sig-
nal which does not go to ground) this new zero reference
should be properly adjusted first A V
IN (a) voltage which
equals this desired zero reference plus LSB (where the
LSB is calculated for the desired analog span using 1 LSB
e analog span 256) is applied to selected ‘‘a’’ input and
the zero reference voltage at the corresponding ‘‘b’’ input
should then be adjusted to just obtain the 00
HEX to 01 HEX
code transition
The full-scale adjustment should be made with the proper
V
IN
(b) voltage applied by forcing a voltage to the V
IN
(a)
input which is given by
V IN (a) fs adj e V MAX b 1 5
(V MAX b V MIN )
256
(
where
V MAX e the high end of the analog input range
and
V
MIN e the low end (the offset zero) of the analog range
(Both are ground referenced )
The V REF IN (or V CC ) voltage is then adjusted to provide a
code change from FE
HEX
to FF
HEX
This completes the ad-
justment procedure
