Functional Description
(Continued)
TABLE II MUX Addressing ADC08038 (Continued)
Differential MUX Mode
MUX Address Analog Differential Channel-Pair
START
SGL ODD SELECT 0 1 2 3
DIF SIGN
1 0 0 1 2 3 4 5 6 7
1 0 0 0 0 a b
1 0 0 0 1 a b
1 0 0 1 0 a b
1 0 0 1 1 a b
1 0 1 0 0 b a
1 0 1 0 1 b a
1 0 1 1 0 b a
1 0 1 1 1 b a
TABLE III MUX Addressing ADC08034
Single-Ended MUX Mode
MUX Address Channel
START
SGL ODD SELECT
0 1 2 3
DIF SIGN
1
1 1 0 0 a
1 1 0 1 a
1 1 1 0 a
1 1 1 1 a
COM is internally tied to AGND
TABLE IV MUX Addressing
ADC08032
Single-Ended MUX Mode
MUX Address Channel
START
SGL ODD
0 1
DIF SIGN
1 1 0 a
1 1 1 a
COM is internally tied to AGND
Differential MUX Mode
MUX Address Channel
START
SGL ODD SELECT
0 1 2 3
DIF SIGN
1
1 0 0 0 a b
1 0 0 1 a b
1 0 1 0 b a
1 0 1 1 b a
Differential MUX Mode
MUX Address Channel
START
SGL ODD
0 1
DIF SIGN
1 0 0 a b
1 0 1 b a
