Security

Open

Connection

WEP encryption 64 and 128 bit options
WPA-PSK

WPA2 Enterprise & Personal

IEEE 802.11i-PSK (AES-CCMP)*
TKIP Encryption
SSL2 / SSL3 / TLS1*
Hardware Acceleration for security features

Protocols

Network Drivers

802.11b, 802.11g

Internet

IPv4, TCP, UDP, DHCP Client, DNS Client, ARP, HTTP Server
Other protocols are supported via UWScript, e.g. Telnet

Web Server

Features

Serves web pages from the module
Runs standard user generated HTTP web pages
Provides access to I/O and ADC status
Serves Dynamic Content from UWScripts
Accepts POST inputs for control of scripts
Allows dynamic control of ports

Website Capacity

128kBytes

Power Consumption

Powersave modes

IEEE Powersave Modes 0,1,5 & 6

Current Consumption

Less than 250mA during data transfer with a configurable low power

mode less than 5mA

Supply Voltage

Supply

3.3V – 5.0V DC

Regulation

On-board regulators, brown-out detection and watchdog

Embedded Wireless Processor System

Specification

ARM7 with 16Mb SRAM and 64Mb Flash

Scripting Interpreter

Runs UWScript
Fully featured scripting language with wireless extensions

Data Filing System

User accessible

Script Capacity

128kBytes

Auto-run

Optional Automatic script execution at power on

WLAN functions

Search, Attach, Detach, Security, Region, etc.

Upgradeability

Firmware upgradeable via UART

Coexistence / Compatibility

Bluetooth

2-wire and 3-wire hardware coexistence schemes supported

Pin compatible with EZURiO BISM Bluetooth modules

Connections

Interface

40 way Hirose DF-12 Connector

External Antenna

U.FL connector for 50 Ohm antenna

Available Q3 2007

** Shared between webserver and script storage
