MAX6636
7-Channel Precision Temperature Monitor
______________________________________________________________________________________ 11
REGISTER
ADDRESS
(hex)
POR STATE
(hex)
READ/
WRITE
DESCRIPTION
Local 07 00 R Read local temperature register
Remote 1 01 00 R Read channel 1 remote temperature register
Remote 2 02 00 R Read channel 2 remote temperature register
Remote 3 03 00 R Read channel 3 remote temperature register
Remote 4 04 00 R Read channel 4 remote temperature register
Remote 5 05 00 R Read channel 5 remote temperature register
Remote 6 06 00 R Read channel 6 remote temperature register
Configuration 1 41 00 R/W Read/write configuration register 1
Configuration 2 42 00 R/W Read/write configuration register 2
Configuration 3 43 00 R/W Read/write configuration register 3
Status1 44 00 R Read status register 1
Status2 45 00 R Read status register 2
Status3 46 00 R Read status register 3
Local ALERT High Limit 17 5A R/W Read/write local alert high-temperature threshold limit register
Remote 1 ALERT High Limit 11 6E R/W
Read/write channel 1 remote-diode alert high-temperature
threshold limit register
Remote 2 ALERT High Limit 12 7F R/W
Read/write channel 2 remote-diode alert high-temperature
threshold limit register
Remote 3 ALERT High Limit 13 64 R/W
Read/write channel 3 remote-diode alert high-temperature
threshold limit register
Remote 4 ALERT High Limit 14 64 R/W
Read/write channel 4 remote-diode alert high-temperature
threshold limit register
Remote 5 ALERT High Limit 15 64 R/W
Read/write channel 5 remote-diode alert high-temperature
threshold limit register
Remote 6 ALERT High Limit 16 64 R/W
Read/write channel 6 remote-diode alert high-temperature
threshold limit register
Remote 1 OVERT High Limit 21 6E R/W
Read/write channel 1 remote-diode overtemperature threshold
limit register
Remote 4 OVERT High Limit 24 7F R/W
Read/write channel 4 remote-diode overtemperature threshold
limit register
Remote 5 OVERT High Limit 25 5A R/W
Read/write channel 5 remote-diode overtemperature threshold
limit register
Remote 6 OVERT High Limit 26 5A R/W
Read/write channel 6 remote-diode overtemperature threshold
limit register
Remote 1 Extended
Temperature
09 00 R Read channel 1 remote-diode extended temperature register
Manufacturer ID 0A 4D R Read manufacturer ID
Table 3. Command Byte Register Bit Assignment
