Connection Diagrams
16-Pin Dual-In-Line and
Wide Body SO Packages
TL H 11354 – 6
Top View
20-Pin Dual-In-Line and
Wide Body SO Packages
TL H 11354 – 7 Top View
24-Pin Dual-In-Line and
Wide Body SO Packages
TL H 11354 – 8 Top View
28-Pin Dual-In-Line and
Wide Body SO Packages
TL H 11354 – 9
Top View
Ordering Information
Industrial Temperature Range
Package
b 40 C s T
A s a 85 C
ADC12H030CIN ADC12030CIN N16E
ADC12H030CIWM ADC12030CIWM M16B
ADC12H032CIN ADC12032CIN N20A
ADC12H032CIWM ADC12032CIWM M20B
ADC12H034CIN ADC12034CIN N24C
ADC12H034CIWM ADC12034CIWM M24B
ADC12H038CIN ADC12038CIN N28B
ADC12H038CIWM ADC12038CIWM M28B
