Electrical Characteristics
(Continued)
Note 9
A diode exists between AV
a
and DV
a
as shown below
TL H 11225 – 5
To guarantee accuracy it is required that the AV
a
and DV
a
be connected together to a power supply with separate bypass filter at each V
a
pin
Note 10
Typicals are at T
J
e
T
A
e
25 C and represent most likely parametric norm
Note 11
Tested limits are guaranteed to National’s AOQL (Average Outgoing Quality Level)
Note 12
One LSB is referenced to 10 bits of resolution
Note 13
Total unadjusted error includes offset full-scale linearity multiplexer and hold step errors
Note 14
For DC Common Mode Error the only specification that is measured is offset error
Note 15
Channel leakage current is measured after the channel selection
Note 16
All the timing specifications are tested at the TTL logic levels V
IL
e
0 8V for a falling edge and V
IH
e
2 0V for a rising
Ordering Information
Industrial b
40 C
s
T
A
s
85 C
Package
ADC10154CIN
N24A
ADC10154CIWM
M24B
ADC10158CIN
N28B
ADC10158CIWM
M28B
7
