17

6 Tighten all screws, but do not over-tighten.

You’ll need

F

B

G

GG

I

J

K

L

M

H

HH

NOTE: Your existing TV wall mount may vary from the one shown below. Refer to the
instructions that came with your existing TV wall mount for attaching brackets to the bac
of the TV. However, you MUST use the screws and washers provided with the soundbar
mount instead of the screws and washers that came with your existing wall mount.

NOTE: The soundbar must be
mounted below your TV.

or

or

WARNING: You must use the larger
washers (GG or HH) unless they do
not fit your TV bracket.

G (4)

H (4)

I

(4)

J (4)

K (4)

Phillips screwdriver

or

or

or

L (4)

Level

or

M (4)

F Mount
spacer (2)

B TV bracket arm (2)

or

or

GG (4)

or

HH (4)

RF-SBM101_13-0263_MAN_V1_ENG.fm Page 17 Monday, May 6, 2013 10:53 AM
