16
STEP 5 - Option 1: Attaching the mounting hardware to
TVs with a flat back
1 Place the mount spacers (F) over the top two screw holes on
the back of the TV.
2 Place the TV bracket arms (B) over the bottom two screw
holes on the back of the TV. To make sure the arms are not
visible when on the wall, align the arms so they reach the
bottom or corners of the TV, but do not over hang the edges.
3 Align your existing TV wall mount brackets with the screw
holes on the back of the TV.
4 Install screws (I, J, K, L, or M) and washers (G, GG, H, or HH)
through the top two holes in the wall mount bracket. The TV
brackets should be level on the back of the TV. Do not
tighten.
5 Install screws (I, J, K, L or M) and washers (G, GG, H, or HH)
through the bottom two holes in the wall mount bracket.
Continued on next page.
