Page 8
8
Setting up your wireless rear speaker kit
The following diagram shows a typical home theater setup
using the Wireless Rear Speaker Kit. The following sections
provide further details on how to setup and operate this
product.
Left speaker
Right speaker
Center speaker
Home theater receiver
Wireless
Sender
Wireless
Receiver
Right rear
Left rear
RF-WHTIB_13-0050_MAN_V1_ENG.fm Page 8 Tuesday, March 26, 2013 11:51 AM
