9066-OM (V4.5) 9066 PRODUCT MANUAL 1-1
Chapter 1
Chapter 1
Introduction
Overview
This manual provides installation and operating instructions for the
9066 Upconverter with Analog/SDI Input, Audio Embed/De-Embed, Frame
Sync, Timecode and Closed Caption Support card (also referred to herein as
the 9066).
This manual consists of the following chapters:
• Chapter 1, “Introduction” – Provides information about this manual
and what is covered. Also provides general information regarding the
9066.
• Chapter 2, “Installation and Setup” – Provides instructions for
installing the 9066 in a frame, and optionally installing 9066 Rear I/O
Modules.
• Chapter 3, “Operating Instructions” – Provides overviews of
operating controls and instructions for using the 9066.
This chapter contains the following information:
• 9066 Card Software Versions and this Manual (p. 1-2)
• Manual Conventions (p. 1-3)
• Safety Summary (p. 1-4)
• 9066 Functional Description (p. 1-5)
• Technical Specifications (p. 1-23)
• Warranty and Service Information (p. 1-27)
• Contact Cobalt Digital Inc. (p. 1-28)
