Introduction
Technical Specifications
Technical Specifications
Table 1-3 lists the technical specifications for the 9066 Upconverter with
Analog/SDI Input, Audio Embed/De-Embed, Frame Sync, Timecode and
Closed Caption Support card.
Table 1-3 Technical Specifications
Item Characteristic
Part number, nomenclature 9066 Upconverter with Analog/SDI Input, Audio Embed/
De-Embed, Frame Sync, Timecode and Closed Caption Support
Installation/usage environment Intended for installation and usage in frame meeting openGear™
modular system definition.
Power consumption < 24 Watts maximum
Environmental:
Operating temperature:
Relative humidity (operating or storage): 32° – 104° F (0° – 40° C)
< 95%, non-condensing
Frame communication 10/100 Mbps Ethernet with Auto-MDIX.
Indicators Card edge display and indicators as follows:
• 4-character alphanumeric display
• Status/Error LED indicator
• Input Format LED indicator
Controls Card edge switches as follows:
• Menu Enter pushbutton switch
• Menu Exit pushbutton switch
• Up/down selection toggle switch
Internal Tone Generators Four built-in tone generators, each configurable for 18 discrete
sine wave frequencies ranging from 50 Hz to 16 kHz.
Generator source signal level is equivalent to -20 dBu.
A/D Process 8:8:8
Resolution: 12-bit A/D and 10-bit video data path
SD Comb Filter: 5-line adaptive
Serial Digital Video Input Data Rates Supported:
SMPTE 259M-C SD-SDI: 270 Mbps
Impedance:
75
Ω
terminating
