4-12 •••• Menus 9215-EO-EM User Manual •••• (V 1.1)
Menu Item Parameters Description
Checkbox selected*
Hardware Status field reports when
a rear module is not compatible with
the card
Hardware
Incompat Rear
Module
Checkbox unselected Disables the alarm
Checkbox selected*
Hardware Status field reports when
the temperature of the SFP module
is not in range (high/low)
Alarm on
Abnormal
Temperature
Checkbox unselected Disables the alarm
Checkbox selected*
Hardware Status field reports when
the power consumption of the SFP
module is not in range (high/low)
Alarm on
Abnormal Power
Checkbox unselected Disables the alarm
Checkbox selected*
Hardware Status field reports when
the optical module is not detected
Optical
Module
Alarms
Alarm on Not
Detected
Checkbox unselected Disables the alarm
Checkbox selected*
Signal Status field reports when a
group is not present on the input
Group not present
Checkbox unselected Disables the alarm
Checkbox selected*
Signal Status field reports when the
specified channel is detected as
silent
Embedded
Input
Audio -
Group #
Channel # Silent
Checkbox unselected Disables the alarm
Checkbox selected*
Signal Status field reports when the
source for the specified input is not
present
Input no present
Checkbox unselected Disables the alarm
Checkbox selected*
Signal Status field reports when the
specified channel is detected as
silent
AES
Inputs -
AES #
Channel # Silent
Checkbox unselected Disables the alarm
Checkbox selected*
Embedded Audio Status field
reports when the selected source is
not present or is silent
Source Missing
Checkbox unselected Disables the alarm
Checkbox selected*
Embedded Audio Status field
reports when the selected source is
asynchronous to the input video
Embedded
Outputs -
Group #
Source Async
Checkbox unselected Disables the alarm
