9071-OM (V4.0) 9071 PRODUCT MANUAL 1-9
Introduction
9071 Functional Description
9071 Rear I/O Modules
The 9071 physically interfaces to system video connections at the rear of its
frame using a Rear I/O Module.
All inputs and outputs shown in the 9071 Functional Block Diagram (Figure
1-1) enter and exit the card via the card edge backplane connector. The
Rear I/O Module breaks out the 9071 card edge connections to BNC
connectors that interface with other components and systems in the signal
chain.
These required BNC connections are provided by either an 8310-BNC or
8310-C-BNC frame (which both have a built-in BNC connector backplane
module), or by using an optional 9071 Rear I/O Module.
Video Formats Supported by the 9071
The 9071 supports all current SMPTE standard SD and HD video formats.
Table 1-1 lists and provides details regarding the audio and video formats
supported by the 9071.
Table 1-1 Supported Audio and Video Formats
Item Description/Specification
SDI Input / Output Video Raster Structure: Frame Rate:
1080PsF 23.98; 24
1080p 23.98; 24
1080i
(1)
25; 29.97; 30
720p 23.98; 24; 25; 29.97; 30; 50; 59.94;
60
486i
(1)
29.97
575i
(1)
25
(1) All rates displayed as frame rates; interlaced (“i”) field rates are two times the rate value shown.
