9232 Owner’s Manual (V 1.1) 21
Table 3. 9232 
Technical Specifications
Category Parameter Specification
Number of Inputs 1 (Looping*)
Input Impedance 75Ω terminating
Return Loss 43dB to 5MHz, 35dB to 20MHz
Analog Input
Nominal Signal Level 1Vpp (video, AES-3id)
Number Of Outputs 8
Output Impedance 75Ω
Output Return Loss 45dB to 5MHz, 41dB to 20MHz
Output Isolation 51dB to 5MHz, 40dB to 20MHz
DC Offset <30mV
Frequency Response ±0.08dB to 10MHz, ±0.2dB to 20MHz
Differential Phase <0.1 ˚ in NTSC, <0.3 ˚ in PAL
Differential Gain <0.1% in NTSC, <0.1% in PAL
Analog
Outputs
RMS Noise (unweighted) 68dB
Gain Range ±3dB
Gain Stability <0.2% per 10 ˚ C
Delay
7ns (9 ˚ @ 3.58MHz) NTSC
7ns (11 ˚ @ 4.43MHz) PAL
Chrominance-to-Luminance Delay <2.0ns
Line Rate Window Tilt <0.1%
Field Rate Window Tile <0.1%
Performance
(all outputs
loaded)
Bandwidth -3dB @ 56MHz Typical
Power Total Power Draw <1.5W
*Looping only available with the RM-9232-B Rear Module.
Specifications are subject to change without notice
