9232 Owner’s Manual (V 1.1 18
Status Menus
The following table summarizes the Status Menu options available in DashBoard.
Table 1. Status Menus
Menu Item Parameters Description
Product 9232
Supplier Cobalt Digital Inc.
Board Rev ##
Serial Number ######-###
Product
(Read-only)
Software Rev #.##
Voltage (mV) # Supply Voltage
Current (mA) #
Current consumption of
card
Rear Module # Rear module for the card
CPU Headroom # Processing power available
RAM Available (bytes) #
On-board processing
memory available
Hardware
(Read-only)
EE Bank # Storage count
Green – Video Present
Card is passing valid
analog video
Green – AES/Other
Card is passing AES audio
or other analog signal
Green – No input
No input present or the
signal is below the
detection threshold. The
Notify on Loss of Input
option is disabled.
Signal Status
Red – No input
No input present or the
signal is below 0.5V p-p.
The Notify on Loss of
Input option is enabled.
480i 59.94
720p 59.94
1080i 59.94
1080p 29.97
576i 50
720p 50
1080i 50
1080p 25
Indicates the valid video
format detected
Unknown Video
Indicates a video signal is
present but is an unknown
format
Signal
(Read-only)
Signal Format
AES/Other
Indicates an audio or other
analog signal is detected
