9232 Owner’s Manual (V 1.1)

17

Control and Monitoring

In This Chapter

This section provides a detailed explanation on using remote control functions with your 9232.

The following topics are discussed:

DashBoard Control System

SNMP Monitoring and Control

DashBoard Control System

The DashBoard Control System™ enables you to monitor and control openGear

®

frames and controller

cards from a computer. DashBoard communicates with other cards in the frame through the MFC-
8320-N Network controller card. This card is required in order to use DashBoard to configure the
9232.

The DashBoard software and manual can be downloaded from the Cobalt Digital website.

Using the Menus

You must first install the DashBoard Control System on your computer. Refer to the DashBoard
Owner’s Manual
for software installation procedures and using the DashBoard interface.

The following tables and sections describe the menus, items, and parameters available from the
DashBoard Control System for the 9232.
