17
This setup uses both AUDIO OUT and AUX. OUT of an MF-103
Phaser. When the phaser's RESONANCE control is turned up, the
AUDIO OUT i
s highly colored but the AUX. OUT is not. The
instrument signal goes first through the phaser. The AUX OUT goes
directly to one input on your amplifier or mixer, while the main
AUDIO OUT
goes through the MF-104Z. Thus, the direct sound is not
colored, but the echoes swirl because of the phaser modulation.
MF-104Z SETTINGS:
MIX 10
DELAY TIME 0.2 to 0.3
FEEDBACK 7
Left Switch SHORT
Right Switch INT.LOOP
MF-103 PHASER SETTINGS:
RATE 2
AMOUNT 7
SWEEP 4
RESONANCE 8
Left SwitchHI
Right Switch 12-STAGE
CONNECTIONS:
• Instrument to MF-103 AUDIO IN jack.
• MF-103 AUDIO OUT jack to MF-104Z AUDIO IN jack.
• MF-103 AUX. OUT to first input on your amp or mixer
• MF-104Z AUDIO OUT jack to second input on our amp or mixer
NOTE: The following information on the next page is intended for
use by people who understand analog circuitry and have enough
practical experience to interconnect sophisticated electronic
equipment correctly.
TECHNICAL INFORMATION
