TOPDRY
Prices and Specifications subject to change without notice. • 888-GSI-BINS • Fax 800-800-5329 • www.gsiag.com
April 4, 2011
Batch Series - Shelled Corn
(Metric Measurements)
Batch Series
7.32m Dia.
1-Fan
9.14m Dia.
1-Fan
9.14m Dia.
2-Fan
10.97 Dia.
1-Fan
10.97 Dia.
2-Fan
Fan &
Heater
Unit(s)
Plenum
Temper-
ature C°
Moisture
Content
Wet Basis
Bu/Hr
Batch
Time
Hours
Bu/Hr
Batch
Time
Hours
Bu/Hr
Batch
Time
Hours
Bu/Hr
Batch
Time
Hours
Bu/Hr
Batch
Time
Hours
11.19 kW
91.44 cm
1.125
Million
kCal
60
20%
10.1
2.5
11.7
3.3
18.5
1.9
13.2
4.1
21.4
2.6
25%
6.4
3.8
7.4
5.1
11.7
3.3
8.2
6.5
13.5
4.0
30%
4.0
6.1
4.6
8.2
7.2
5.2
5.2
10.4
8.5
6.5
71
20%
12.0
2.0
14.0
2.8
22.1
1.8
15.8
3.4
25.5
2.1
25%
7.6
3.2
8.8
4.4
14.0
2.7
10.0
5.4
16.2
3.4
30%
4.8
5.2
5.5
6.8
8.7
4.4
6.2
8.7
10.1
5.4
82
20%
15.4
1.6
17.2
2.4*
28.2
1.4
17.6
3.4*
32.6
1.6
25%
9.8
2.6
10.9
3.7*
17.9
2.1
11.2
5.2*
20.7
2.7
30%
6.1
4.0
6.8
6.0*
11.2
3.4
7.0
8.3*
12.9
4.2
11.19 kW
101.6 cm
1.125
Million
kCal
140
20%
12.3
2.0
14.3
2.4
16.5
3.3
25.9
2.1
25%
7.8
3.1
9.0
4.2
10.4
5.2
16.4
3.3
30%
4.9
4.9
5.6
6.7
6.5
8.4
10.3
5.3
160
20%
14.7
1.6
17.0
2.2
19.7
2.8
31.0
1.8
25%
9.3
2.6
10.8
3.5
12.5
4.4
19.6
2.8
30%
5.8
4.2
6.7
5.6
7.8
7.1
12.3
4.5
180
20%
18.9
1.3
21.8
1.8
22.6*
2.6*
39.6
1.4
25%
11.9
2.0
13.8
2.7
14.3*
4.1*
25.1
2.2
30%
7.5
3.3
8.6
4.4
8.9*
6.5*
15.7
3.5
22.37 kW
106.6 cm
1.125
Million
kCal
140
20%
16.2
2.4
18.2
2.9
29.0
1.9
25%
10.3
3.6
11.5
4.7
18.4
2.9
30%
6.4
5.9
7.2
7.5
11.5
4.7
160
20%
19.4
2.0
21.7
2.5
34.6
1.5
25%
12.3
3.1
13.8
4.0
21.9
2.5
30%
7.7
4.9
8.6
6.4
13.7
4.0
180
20%
24.8
1.5
27.2
2.0
44.3
1.3
25%
15.7
2.4
17.6
3.1
28.1
2.0
30%
9.8
3.9
11.0
4.9
17.5
3.2
29.83 kW
106.6 cm
2.5
Million
kCal
140
20%
18.5
2.1
20.6
2.7
25%
11.7
3.3
13.0
4.2
30%
7.3
5.2
8.1
6.7
160
20%
22.0
1.8
24.5
2.2
25%
13.9
2.7
15.5
3.5
30%
8.7
4.4
9.7
5.6
180
20%
28.2
1.4
31.4
1.8
25%
17.8
2.1
19.9
2.7
30%
11.2
3.4
12.4
4.4
* Insufficient burner BTUs for 45 deg. ambient temp
rating exclude loading time.
1/3 CFM/bu
cooling rate
Est. at temp 45 deg. F, rel. humidity 65%
Use only as a guide, conditions will vary capacities.
