1100 Series Parts Manual
Top Auger bearing support.
Top Auger bearing support (inside view).
Top Auger With Wet Bin Assembly
17
16
15
10
21
22
18
19
20
22
21
7
23
24
25
7
16
ITEM
NUMBER
PART NUMBER
DESCRIPTION
1108
1110
1112
1114
1116
1118
1120
1122
1126
1
D01-1521
WET BIN SIDE,4'SIDE GALV. PERF
4
2
4
2
4
2
4
1
D01-1522
WET BIN SIDE,6'SIDE GALV. PER
2
4
2
4
6
4
6
6
2
D01-0103
MERCURY SWITCH SHAFT
1
1
1
1
1
1
1
1
1
3
D21-0003
TOP EDGE ANGLE 71.875"
4
2
2
3
D31-0004
TOP EDGE ANGLE 95.875"
2
2
4
2
4
4
3
D01-0168
TOP EDGE ANGLE 119.875"
2
2
4
2
3a
D31-0003
TOP EDGE ANGLE SPLICE
2
2
2
2
2
4
4
5
D01-0147
TOP AUGER HOUSING HINGE L.H.
2
2
2
2
2
2
2
2
2
6
D01-0167
MERCURY SWITCH PADDLE WELDMENT
1
1
1
1
1
1
1
1
1
7
D01-0811
AUGER TOP WELDMENT 8' BASKET
1
7
D01-0812
AUGER TOP WELDMENT 10'BASKET
1
7
D21-0015
AUGER TOP FRONT WELDMENT
1
1
1
7
D01-0608
AUGER TOP FRONT WLDT 16'BASKET
1
7
D31-0091
AUGER TOP FRONT WELDMENT
1
1
1
7
D01-0801
AUGER TOP/BOT REAR WLD.12'BASK
1
7
D31-0267
AUGER TOP & BOTTOM WELDMENT
1
1
1
2
2
7
D61-0184
AUGER WELDMENT 117 7/8"
1
8
D01-0148
TOP AUGER HOUSING HINGE R.H.
2
2
2
2
2
2
2
2
2
9
D01-1525
WET BIN END
2
2
2
2
2
2
2
2
2
10
D21-0002
TOP AUGER TROUGH SIDE/6'
2
2
10
D31-0010
TOP AUGER TROUGH SIDE/8'
2
2
4
2
4
4
10
D01-0161
TOP AUGER TROUGH SIDE/10'
2
2
4
2
11
D01-1650
REAR AUGER BEARING COVER
1
1
1
1
1
1
1
1
1
12
D31-0028
TOP AUGER HOUSING END
2
2
2
2
2
2
2
2
2
13
D32-0001
BEARING 1 1/2" DIA W/FLANGETTE
2
2
2
2
2
2
2
2
2
14
D31-0090
SHAFT, TOP AUGER FRONT (with keyway)
1
1
1
1
1
1
1
1
1
14a
D31-0005
SHAFT, TOP AUGER STUB REAR
1
1
1
1
1
1
1
1
1
15
D01-1123
TOP AUGER COVER, 30.25"
1
1
1
1
1
1
1
1
1
15
D01-1124
TOP AUGER COVER, 24.25"
2
3
2
3
4
5
7
5
7
15
D01-1125
TOP AUGER COVER, 20.25"
2
2
2
2
2
4
4
16
D31-0015
TOP AUGER BEARING SUPPORT
1
1
1
1
1
2
2
17
D31-0011
CENTER STABILIZER BEAM
1
1
1
1
1
2
2
18
D31-0009
GUSSET ATTACH BRACKET
2
2
2
2
2
4
4
19
D31-0001
CENTER HANDRAIL GUSSET L.H.
2
2
2
2
2
4
4
20
D31-0002
CENTER HANDRAIL GUSSET R.H.
2
2
2
2
2
4
4
21
D21-0001-Y
HAND RAIL-SUPPORT,1"EMTX71.75"
4
2
2
21
D31-0006-Y
HAND RAIL SUPPORT,1"EMTX95.75"
2
2
4
2
4
4
21
D01-0151-Y
HAND RAIL, 1"EMT X119.75"LONG
2
2
4
2
22
D01-0140
HANGER BRACKET-HANDRAIL GALV.
8
8
16
16
16
16
16
24
24
23
D31-0008
TOP AUGER TROUGH SPLICE
2
2
2
2
2
4
4
24
D01-1245
TOP AUGER BEARING HANGER ASSY.
1
1
1
1
1
2
2
25
D31-0076
SHAFT, AUGER SPLICE
1
1
1
1
1
2
2
