- 13 -
1100 Series Parts Manual
Meter Roll Upper Shield Assembly
Close up of of meter roll upper shield assembly.
16
17
18
19
18
17
19
ITEM
NUMBER
PART NUMBER
DESCRIPTION
1108
1110
1112
1114
1116
1118
1120
1122
1126
1
D01-0110
COLUMN BULK HEAD
6
8
N/A
N/A
N/A
N/A
N/A
N/A
N/A
1
D31-0055
COLUMN BULK HEAD
N/A
N/A
10
12
14
16
18
20
24
2
D01-0101
GARNER BULKHEAD
6
8
10
12
14
16
18
20
24
3
D01-0121
COLUMN END PANEL-LOW PRO
4
4
N/A
N/A
N/A
N/A
N/A
N/A
N/A
3
D31-0307
COLUMN END PANEL
N/A
N/A
4
4
4
4
4
4
4
4
D01-0126
SCREEN,PLENUM TOP,GA,094
8
10
12
14
16
18
20
22
26
5
D01-0125
SCREEN,PLENUM WALL,GA,094
8
10
N/A
N/A
N/A
N/A
N/A
N/A
N/A
5
D31-0012
SCREEN,PLENUM WALL,GA,094
N/A
N/A
12
14
16
18
20
22
26
6
D01-1225
SCREEN,PLENUM BOTTOM,GA,094
8
10
12
14
16
18
20
22
26
7
D01-0004
GUSSET PLATE
10
12
14
16
18
20
22
24
28
8
D11-0005
FRAME RAIL, 8' RIGHT
1
8
D01-0010
FRAME RAIL, 10' RIGHT
1
8
D51-0002
FRAME RAIL, 12' RIGHT
1
8
D21-0011
FRAME RAIL, 14' RIGHT
1
8
D01-0538
FRAME RAIL, 16' RIGHT
1
8
D31-0044
FRAME RAIL, 18' RIGHT
1
8
D61-0002
FRAME RAIL, 20' RIGHT
1
8
D101-0002
FRAME RAIL, 22' RIGHT
1
8
D71-0001
FRAME RAIL, 26' RIGHT
1
9
D11-0004
FRAME RAIL, 8' LEFT
1
9
D01-0009
FRAME RAIL, 10' LEFT
1
9
D51-0001
FRAME RAIL, 12' LEFT
1
9
D21-0010
FRAME RAIL, 14' LEFT
1
9
D01-0537
FRAME RAIL, 16' LEFT
1
9
D31-0043
FRAME RAIL, 18' LEFT
1
9
D61-0001
FRAME RAIL, 20' LEFT
1
9
D101-0001
FRAME RAIL, 22' LEFT
1
9
D71-0002
FRAME RAIL, 26' LEFT
1
10
D01-0007
CORNER LEG PORTABLE DRYER
4
4
6
6
6
6
6
8
8
11
D01-0012
HITCH BRACKET RIGHT
1
1
1
1
1
1
1
1
1
12
D01-0011
HITCH BRACKET LEFT
1
1
1
1
1
1
1
1
1
13
D01-0008
FRONT & REAR FRAME TIE CHANNEL
2
2
4
4
4
4
4
6
6
14
D01-1374
BOTTOM AUGER BEARING PLATE
1
1
1
1
1
1
1
1
1
15
D01-0005
SIDE LEG PORTABLE DRYER
6
8
8
10
12
14
16
16
20
16
D01-0109
HOPPER BULKHEAD
6
8
10
12
14
16
18
20
24
17
D01-0050
CONNECTOR SHEET
8
10
12
14
16
18
20
22
26
*18&19
D01-1180
METER ROLL UPPER SHIELD ASSY.
8
10
12
14
16
18
20
22
26
18
D01-0431
METER ROLL STRIKE OFF PLATE
19
D01-1226
METER ROLL SHIELD 1995 STYLE
1 PER ASSEMBLY
1 PER ASSEMBLY
*ITEM NUMBERS 18 AND 19 TOGETHER MAKE UP THE METER ROLL UPPER SHIELD ASSEMBLY
