4. Monorail Installation
18 PNEG-1827 36' Dura-Lok Plank and Support Manual
Monorail “Rail and Leg Spacing”/“Full Floor Leg Quantity” for 36' Bin Diameter
4.00"
Ring
2.66"
Ring
Eave Height (ft.) Rail Spacing
Reference
Page
Leg Spacing Leg Qty
3 4 11 26 See Page 36 26 281
4 6 16 26 See Page 36 23 316
5 8 22 26 See Page 36 21 345
7 10 27 26 See Page 36 19 380
9 12 33 22 See Page 34 19 438
10 14 38 22 See Page 34 18 462
11 16 43 22 See Page 34 18 462
13 18 48 20 See Page 32 18 495
14 20 54 20 See Page 32 17 523
16 22 59 18 See Page 30 17 568
17 24 64 18 See Page 30 17 568
19 26 70 17 See Page 28 16 624
20 28 75 17 See Page 28 16 624
22 30 81 16 See Page 26 16 659
23 32 86 16 See Page 26 15 702
