PNOT-305 4
Product Notification
PNOT-305
Vision Touch Control Board Fuse
Replacement Instructions
Step 6A: Flip the internal touch screen board over
as shown in figure F. Locate the 5amp fuse holder
and replace the fuse.
Occasionally the fuse may be difficult to pull the
first time. The easiest way to pull the fuse in this
instance is to use the thumb and index finger and
hold it as shown in figure C on page 2 and pull
the fuse using a rocking motion.
5 amp Fuse
Figure F: Replace fuse.
