PNOT-305 2
Step 4: Locate the 5amp fuse holder and pull the
fuse out (see figure C). If you DO NOT see a
fuse, then procede to Step 4A on the next page.
Occasionally the fuse may be difficult to pull the
first time. The easiest way to pull the fuse in this
instance is to use the thumb and index finger and
hold it as shown in figure C and pull the fuse using
a rocking motion.
Step 5: Replace the fuse with a new one (part no.
E300-1013) and reassemble the touch control
computer.
Product Notification
PNOT-305
Vision Touch Control Board Fuse
Replacement Instructions
5 amp Fuse
Figure C: Replace fuse.
