Page 4 of 9 PNEG-1856
Baldor Motor Kit
Programming Baldor H2 and VS Drives on Dryers Built
1994-1997 (Continued)
All parameters and their settings to be changed for Zimmerman purposes shown in chart below .
NOTE: After programming is complete if local is displayed in upper right hand corner of status screen.
Then Local/Remote button will have to be pressed to change to remote. This is a one time
operation and will not have to be done in the future.
* NOTE: Accutrol Unload Dryers Only - 5 amps is selected for 17' diameter dryers, 6 amps for
23'-4" diameter dryers. Dryers with metering augers stay at factory setting.
Top Level
Programming Menu
1 st Level
Parameter Group
Individual
Parameters
Settings
Zimmerman Changes
Level 1 Blocks Ramp Rates Accel Time #1 3 Seconds
Decel Time #1 3 Seconds
Level 1 Blocks Keypad Setup Stop Key OFF
Stop Mode Coast
Run Forward OFF
Run Reverse OFF
Level 1 Blocks Input Setup Operating Mode Standard Run 3 Wire
Command Source Analog In2
Analog In2 Type 0-5V
Level 1 Blocks Output Setup Analog Out 1 Type 0-5V
Level 2 Blocks Drive Limits Minimum Output Speed 7 Hertz
Maximum Output Speed 75 Hertz
Level 2 Blocks Drive Protect External Trip ON
Level 2 Blocks Motor Data Motor Rated Amps Factory/5 Amps or 6 Amps*
Press R to Exit Press R to Exit Press R to Exit
Press ENTER at Status
