PNEG-970 S2 Hopper w/ Collector Ring
23
Assembly
stranded wires
4. ASSEMBLE THE CROSSBRACE TO THE SWEEP
A. Feed the nine (9) stranded wires from the collector ring through the pivot tube and hole in the
back of the sweep head section.
B. Align the hole in the backshield with the pivot tube and push the sweep onto the pivot tube.
