Mounting The Six-Gun/EconoMind

Diesel Tuner

20.

2003-04 model year vehicles only:

Remove the clip shown in Figure 12

to create adequate room to mount the

Six-Gun/EconoMind Diesel Tuner to the

driver side inner fender.

21.

2003-04 four-wheel drive

vehicles: The module shown in Figure

13 will appear only in four-wheel-

drive vehicles. This may need to be

relocated to make room for the Six-

Gun/EconoMind Diesel Tuner. The

mounting location of this module by

the factory has not been consistent on

early vehicles.
NoTE: Make sure all mounting surfaces

are entirely clean and free of dirt

and oil before mounting the Six-Gun/

EconoMind Diesel Tuner. Clean and

dry as required using a cloth damped

in rubbing alcohol or similar cleaning

solution.

21.

2005-07 model year vehicles only:

Remove the adhesive backing from two

(2) dual-lock fasteners and attach them

to the Six-Gun/EconoMind shield and

the top of the fuse box.

22.

Remove the adhesive backing

from the (2) dual-lock fasteners on the

back of the Six-Gun/EconoMind Diesel

Tuner and affix the tuner to:
2003-04 model year vehicles: The inner

driver side fender as shown in Figure 3
Note: Shield will not be used for

installations on 03-04 models. Shield

will only be used on 05-07 models.
2005-07 model year vehicles: The inside

roof of the Six-Gun/EconoMind shield,

that is mounted on the fuse box cover

as shown in Figure 4 & 6.
WARNING: The use of Banks Brake

is for use with installed Six-Gun/

EconoMind Tuner Package with

power level selector switch only.

-END, SEcTION 1-
