6

96507 v.4.0

Use caution when working in the

engine compartment. Make sure the

engine has been OFF for several hours

and cool. Disconnect the ground

cables from both the driver and

passenger side batteries. Position the

loose cables so that they do not come

into contact with their respective

battery posts during the installation.

1.

Loosen the hose clamp from the

stock intake tube on the turbo intake.

2.

Loosen and separate the stock

hose clamp on the intake air tube

connected to the stock air box cover.

See Figure 1.

3.

Separate the stock intake tube

connected to the turbo intake. Remove

the stock intake tube from the engine

and set aside.

4.

Remove the Mass Air Flow (MAF)

sensor connector from stock air box

filter cover.

Note: Be careful not to damage the

connector or the MAF sensor during

this process.

5.

Remove stock air box by lifting the

air box up and out. The bottom of the

stock air box is held in place by rubber

grommets. There may be some slight

resistance when removing the stock

air box.

6.

Next, remove the stock air box

bolts accessible from the top of the

engine compartment as shown. Then

remove the stock air box tray. See

Figure 2. Keep the previously removed

bolts for reassembly later in the

installation process.
If you are installing the Banks Techni-

Cooler, skip to Section 3.

7.

Locate your Banks Ram-Air filter

housing from your kit. Align the Banks

Ram-Air filter housing to fit parallel to

fender edge. Install and tighten the

Figure 1
