Banks Power Chevy_GMC Trucks: Duramax LMM (Diesel ’07 - 10 6.6L) Power Systems- PowerPack & Stinger w_EconoMind ('07-09) LMM (PDA) Compatible w_Optional PowerPDA User Manual
Page 21

96507 v.4.0
21
38.
Install the grill by snapping in the
tabs into the retainer clips.
39.
Install the upper grill baffle
and secure with the seven push-
in retainers that were previously
removed. The push-in retainers that
secure the grill baffle are secured by
inserting the retainer with the center
pin pulled out. Once the retainer is
inserted, press the center pin down to
secure the retainer.
40.
Before slipping any boost tubes
and the corresponding hoses into
position, ensure that all connection
ends are clean and free of any oil
residue and contaminates. Clean the
compressor outlet and all connection
points with a non-oil based solvent
such as Acetone, Mineral Spirits,
Denatured Alcohol or Lacquer Thinner.
Read and follow the manufactures
operation instruction for non-oil based
solvent cleaner.
Note: Make sure to remove any rags
or items that were used to cover the
turbo and intake manifold openings
before installing the boost tubes.
41.
Install the driver and passenger
side boost tubes. Tighten the driver
side hose clamps to 75 in-lbs. Make
sure when reinstalling the passenger
side boost tube that the hose coupler
fits tight and flush to its respective
mounting location, then reinstall the
wire retaining clip.
Note: The a/c line that runs near the
intake manifold will need to be bent
downward to provide clearance for the
boost tube. The a/c line can be bent
by placing a wooden block on the a/c
line, then lightly tapping the block with
a hammer.
42.
Install the lower air cleaner
support bracket. Tighten the bolts to
80 in-lbs.
Return back to Section1, step 7.
-END, SEcTION 3-
