Banks Power Chevy_GMC Trucks: Duramax LMM (Diesel ’07 - 10 6.6L) Power Systems- PowerPack & Stinger w_EconoMind ('07-09) LMM (PDA) Compatible w_Optional PowerPDA User Manual
Page 58
58
96507 v.4.0
If the EconoMind Diesel Tuner has
been moved to a different vehicle,
or you are instructed to do so by
Banks Technical Staff, it is possible to
reset all of the parameters that the
EconoMind has ‘learned’ - presence of
an EGT thermocouple, etc.
CAUTION: The following procedures
can only be carried out with the
engine OFF!
1.
Turn the vehicle key to ON but DO
NOT start the engine.
2.
Fully depress the throttle pedal
and then release it completely.
Repeat 5 times. The Tuner’s GREEN
LED will flash when this is completed
successfully.
3.
Turn the key OFF. Wait 60 seconds
and make sure the GREEN LED goes
off and stays off. Turn the key back to
the ON position but DO NOT start the
engine.
4.
Fully depress the throttle pedal and
then release it completely. Repeat 5
times.
5.
The EconoMind Tuner has
now been cleared of all ‘learned’
parameters and will now be in
a factory-default state, as it was
originally shipped.
-END, SEcTION 14-
Section 13
CLEARING LEARNED INFORMATION
If the EconoMind Diesel Tuner should
ever need to be removed from the
vehicle, perform the following:
1.
Disconnect the negative (ground)
cable from the battery (or batteries, if
there are two) before beginning work.
2.
Disconnect the EconoMind’s gray
connector from the factory harness.
3.
Re-connect the vehicle’s gray
connector back into the factory
harness.
4.
Disconnect the EconoMind’s black
connector from the factory harness.
5.
Re-connect the vehicle’s black
connector back into the factory
harness.
6.
Disconnect the EGT thermocouple
connector. The thermocouple may be
left in place or removed if a suitable
plug is used.
7.
Disconnect the ‘In-Cab Cable’ and
gently pull the cable back through the
firewall.
8.
Remove the EconoMind Diesel
Tuner. Failure to follow the above
instructions when removing the Tuner
will result in a “Check Engine” light
on the dash and a Diagnostic Trouble
Code being stored in the factory
computer, in addition to the engine
not running.
9.
Re-connect the negative (ground)
cable(s).
-END, SEcTION 15-
Section 14
REMOVAL OF THE ECONOMIND DIESEL TUNER
