Banks Power Ford Trucks: (Diesel ’03 - 07 6.0L Power Stroke) Interface- PowerPDA For use with EconoMind Ford (03-09), Chevy(01-08), Dodge (03-07) User Manual
Page 26
Checking for Engine Diagnostic
Codes:
1.
Press the center button on the
5-way navigator to take you the
System Menu screen.
2.
Next, touch the ‘OBD II’ button.
3.
With the ignition in the on/run
position or with the engine running,
touch the button labeled ‘check For
codes’. See Figure 43.
Note: On Dodge vehicles and
motorhomes, the ignition key must be
in the On/Run position, but the engine
must NOT be running. If the engine is
running, Banks PowerPDA will display
a pop-up message instructing you to
check the ignition key is in the ON
position.
The Banks PowerPDA will check
for vehicle diagnostic codes and
display either the error code with a
brief description of the code or the
message “Done! – No codes Present”.
For a full description of the code,
highlight the code and a window will
pop up with a detailed explanation.
4.
To return to the System Menu
touch ‘ found and you would like to clear them, proceed to step 5. Clearing Engine Diagnostic Codes: 5. After checking for and reviewing any diagnostic codes, touch ‘clear codes’ to erase them from the vehicle PcM. If multiple codes are present, they will all be cleared. motorhomes, the ignition key must be in the On/Run position, but the engine must NOT be running. If the engine is running, Banks PowerPDA will display a pop-up message instructing you to check the ignition key is in the ON position. 6. Press ’check For codes’ again to verify the engine codes were erased. Some status monitor codes require a certain amount of engine “run time” in order to be cleared (i.e. P1000 on Ford). 7. If diagnostic codes re-occur on your vehicle, you should investigate the underlying problem to correct it. -END SEcTION 11- Section 11 ChECKING AND CLEArING ENGINE DIAGNoSTIC CoDES Figure 43 26 96803 v.7.0
Note: On Dodge vehicles and
