22
96581 v.7.0
WARNING: If the Bullet Diesel Tuner
is installed in tandem, or ‘stacked’
with another performance diesel
tuner that modifies the amount
of fuel injected into the engine,
the Bullet diesel tuner may not
be able to control EGT within the
set limit as it is not able to control
the functions of the secondary
performance diesel tuner.
ALWAYS CAREFULLY MONITOR
YOUR EGT WHEN RUNNING
STACKED PERFORMANCE
DIESEL TUNERS.
Setting Default Display Options:
To set the desired default display
parameter from the normal display
mode, press the ‘MENU’ button until
‘DISP’ is displayed, then press the
‘SELEcT’ button.
The currently selected engine parameter
is displayed – to continue operating
with this parameter displayed by default
on the Bullet diesel tuner, press the
‘SELEcT’ button – a ‘SAvED’ message
will be displayed and the diesel tuner will
return to the normal display mode. To
cycle through the available parameter
display options, press the ’MENU’
button. ‘EGT’ will display the Exhaust
Gas Temperature from the thermocouple
(if installed); ‘BST’ will display boost
(manifold) pressure; ‘FUEL’ will display
the amount of fuel entering the engine
as a percentage of the stock fuel
amount. ’vER’ will display tuner part
number and current firmware/calibration
version.
Press the ‘SELEcT’ button to set the
currently displayed engine parameter as
the default display parameter – the Bullet
diesel tuner will save your selection,
display a ‘SAvED’ message, and return
to the normal display mode where the
parameter you have just selected will
now be displayed on the diesel tuner.
If no buttons are pressed within five
(5) seconds, the diesel tuner will return
to the standard display mode without
saving any changes.
Setting the Boost Level
Set Point:
To set the boost level at which the Bullet
diesel tuner will trigger a visual alarm
warning you of a high boost condition,
press the ‘MENU’ button while in the
normal display mode until ‘B SP’ is
displayed, then press the ‘SELEcT’
button.
The current Boost Level Set Point will
be displayed, in PSI (the default value
is 50 PSI). Press the ‘SELEcT’ button to
continue operating with this Boost Level
Set Point and return to normal operating
mode (the diesel tuner will display a
‘SAvED’ message confirming your
selection), or press the ‘MENU’ button
to cycle through all available Boost Level
Set Point options from 20 PSI to 50 PSI,
in 1 PSI increments.
Press the ‘SELEcT’ button when
your desired Boost Level Set Point is
displayed, and the Bullet diesel tuner will
save your selection, display a ‘SAvED’
message, and return to the normal
display mode. If no buttons are pressed
within five (5) seconds, the diesel tuner
will return to the standard display mode
without saving any changes.
Note: In the normal display mode
‘t SP’ (transmission temperature
Set Point) is a non-functioning
setting for this model vehicle.
this menu will still be accessible
and editable, but the settings it
contains will not have any affect
on the Bullet diesel tuner. Please
disregard this setting.
-EnD, SECTIon 3-
