96581 v.7.0
21
This is the Bullet diesel tuner’s
normal display mode. Power level
selection, EGT limiting, display options
and diagnostics information are all
accessed by pressing the ‘MENU’
button on the face of the diesel tuner.
Setting Desired Power Level:
To set the desired power level from the
normal display mode, press the ‘MENU’
button until ‘PWR’ is displayed, then
press the ‘SELEcT’ button.
The current power level setting will be
displayed – press the ‘SELEcT’ button
to continue operating at this power
level and return to normal operating
mode (the diesel tuner will display a
‘SAvED’ message confirming your
selection), or press the ‘MENU’ button
to cycle through power levels ‘STK’
(stock), ‘TOW’ (tow) and ‘SPT’ (sport).
Press ‘SELEcT’ when your desired
power level is displayed, and the
Bullet diesel tuner will instantly make
the necessary corrections to engine
fueling, display a ‘SAvED’ message
confirming your selection, and return
to the normal display mode. If no
buttons are pressed within five (5)
seconds, the diesel tuner will return
to the standard display mode without
saving any changes.
Quick Power Level Changes:
Power levels can also be quickly
changed at any time from the normal
display mode by pressing the ‘SELEcT’
button. The currently selected power
level will be displayed – pressing the
‘SELEcT’ button again within five
(5) seconds will increase the power
level by one; repeatedly pressing the
‘SELEcT’ button will cycle through
power levels ‘STK’-‘SPT’.
Pressing the ‘MENU’ button will set
the currently displayed power level as
the new operating level, and display a
‘SAvED’ message before returning to
the normal display mode. If no buttons
are pressed within five (5) seconds, the
diesel tuner will return to the standard
display mode without saving any
changes.
Setting Desired Maximum
EGT Limit:
To set the desired maximum EGT
limit and alarm level from the normal
display mode, press the ‘MENU’ button
until ‘TLMT’ is displayed, then press
the ‘SELEcT’ button.
The current EGT limit will be displayed,
in degrees Fahrenheit (the default
value is 900 °F). Press the ‘SELEcT’
button to continue operating with
this EGT limit and return to normal
operating mode (the diesel tuner will
display a ‘SAvED’ message confirming
your selection), or press the ‘MENU’
button to cycle through all available
EGT limit options from 800 °F to 1500
°F, in 50 degree increments.
Press the ‘SELEcT’ button when
your desired maximum EGT limit is
displayed, and the Bullet diesel tuner
will save your selection, display a
‘SAvED’ message, and return to the
normal display mode. If no buttons are
pressed within five (5) seconds, the
diesel tuner will return to the standard
display mode without saving any
changes.
The Bullet diesel tuner will now limit
the measured EGT at or below this
value as much as possible by reducing
the amount of extra fuel that it injects
into the engine. In addition, if the
measured EGT increases 50˚ past the
selected limit, an alarm will trigger and
illuminate the warning light as well as
flashing the current EGT value on the
display.
