34
96420 v.5.0
Section 13
Troubleshooting EconoMind Tuner with PowerPDA
The standard Banks EconoMind Diesel
Tuner requires the engine coolant
temperature (EcT) to be above 110º
before it will add fuel. If you feel that
your EconoMind Diesel Tuner is not
functioning properly, some diagnostics
can be performed. check the Banks
PowerPDA’s Status Indicator for the
“OK” icon. Any EconoMind Tuner fault
will be indicated by the “Banks Engine”
icon (see Figure 22) and its cause
can be investigated by going to the
‘Self Diagnostics’ screen and scrolling
through the list of logged Tuner
events.
1.
Press the center button on the
5- way navigator to take you to the
System Menu screen (Figure 23).
2.
Touch the button labeled ‘More>’
to move to the second screen of the
System Menus.
3.
Next, touch the ‘Self Diagnostics’
button. (See Figure 24)
4.
The ‘Self Diagnostics’ screen
displays a log of diagnostic events
related to the EconoMind Tuner (See
Figure 25). The ‘Logged Events’ list
takes a moment to update each time
this screen is opened (as indicated
by a slight flickering of the list). Once
the list is updated, the most current
event will appear at the top of the list.
Each event has an associated time
stamp and description, which will be
displayed below the list when that
event is highlighted. Each key cycle
of the vehicle produces a minimum of
two logged events. (See Figure 25)
5.
Touch the ‘Down’ or ‘Up’
buttons to scroll through the list of
recorded events. Table 1 lists the
available diagnostic codes and the
recommended course of action for
each.
6.
Touch the center button on the 5-
way navigator (or the ‘Back’ button) to
return to the System-Monitor screen.
-END SEcTION 13-
EconoMind TunEr icon
Figure 22 Figure 24
Figure 25
Figure 23
(uP)
(doWn)
5-WAY
nAViGATor
