96454 v.9.0
17
If your Banks Six-Gun Diesel Tuner
module has been properly installed as
outlined in the previous section, it will
power up and briefly scroll ‘BANKS
POWER’ across the screen, then display
the current power level setting after you
switch your ignition key on.
If the Six-Gun module detects any errors
in installation wiring, sensor readings,
or internal hardware functions, it will
flash a message with the detected errors
immediately after displaying the current
power level setting. Please refer to the
following section, ‘Troubleshooting’, for a
full explanation of the error codes, their
causes, and corrective actions.
NotE: the Six-Gun module will
automatically detect an EGt
thermocouple when one is properly
connected, and will configure the
available menus accordingly. If you do
not have a Banks EGt thermocouple
installed and properly connected to the
Six-Gun module, none of the EGt-related
menus will be displayed.
If the Six-Gun module does not detect
any errors in the system, it will monitor
and display the selected default engine
parameter in the following format:
• Boost is displayed in PSI – the letter ‘B’
and one or two digits
• EGT is displayed in degrees Fahrenheit
– three or four digits with no prefacing
letter
• Fuel amount is displayed as a
percentage of stock fuel amount
entering the engine – the letter ‘F‘ and
three digits
• VER displays the tuner part number
and current firmware/calibration version
This is the Six-Gun module’s normal
display mode. Power level selection, EGT
limiting, display options and diagnostics
information are all accessed by pressing
the ‘MENU’ button on the face of the
module.
Setting Desired Power Level:
To set the desired power level from the
normal display mode, press the ‘MENU’
button until ‘PWR’ is displayed, then
press the ‘SELEcT’ button.
The current power level setting will be
displayed – press the ‘SELEcT’ button to
continue operating at this power level
and return to normal operating mode
(the module will display a ‘SAvED’
message confirming your selection),
or press the ‘MENU’ button to cycle
through power levels ‘L1’ (stock) to ‘L6’
(maximum performance).
Press ‘SELEcT’ when your desired
power level is displayed, and the Six-
Gun module will instantly make the
necessary corrections to engine fueling,
display a ‘SAvED’ message confirming
your selection, and return to the normal
display mode. If no buttons are pressed
within five (5) seconds, the module will
return to the standard display mode
without saving any changes.
Quick Power Level Changes:
Power levels can also be quickly
changed at any time from the normal
display mode by pressing the ‘SELEcT’
button. The currently selected power
level will be displayed – pressing the
‘SELEcT’ button again within five (5)
seconds will increase the power level by
one; repeatedly pressing the ‘SELEcT’
button will cycle through power levels
‘L1’-‘L6’.
Section 3:
OPERATION OF THE SIx-GUN MODULE
