PACKAGE CONTENTS
Before attempting to use this unit, please check the packaging and make sure the following items are
contained in the shipping carton:
• (1) Vanco Powered by Wyrestorm VPW-280754 Matrix Unit
• (1) Power Supply for Matrix Unit (100-240V AC)
• Product Manual
• Mounting brackets with screws
• (1) IR Remote
• (1) IR RX Extension Cable
• (4) IR TX emitters (small for input source)
• (4) IR RX receivers (larger for displays)
SPECIFICATIONS
Dimensions (WxHxD): ............................................... 440mm / 17.3” (W) 42mm / 1.6” (H) 168mm / 6.6”
(D)
Weight (Kg): ............................................................ 2.0 Kg / 4.4lbs
Operating Temperature Range: ................................... 5 to 90 % RH (no condensation)
Operating Humidity Range: ........................................ 0 to +35°C (32 to +95°F)
Video Amplifier Bandwidth: ......................................... 6.75Gbps
Input Video Signal: .................................................... 0.5-1.0 volts p-p
Input DDC Signal: ...................................................... 5 volts p-p (TTL)
Maximum Single Link Range: ...................................... 1080p 36bit Deep Color
Transmission distance: .............................................. 1080p signal up to 70m / 230ft - using VPW-
280773 Display Receiver (Under perfect transmission conditions including straight cable runs with no
electrical interference, bends, kinks, patch panels or wall outlets.)
Video Format Supported: ............................................ VESA: 640x480, 800x600,1024x768, 1280x1024,
1600x1200, 1920x1200 DTV/HDTV: 480i/576i/480p/576p/720p/1080i/1080p
Output Video: ............................................................ HDMI v1.4 with full 3D compatibility with Frame
Sequential (Blu-ray) and Interlaced Stereoscoptic (satellite/cable broadcasts)
Audio Format Supported: ............................................ DTS-HD Master Audio, Dolby True HD, multi-channel
5.1, 7.1, stereo
Power Supply: .......................................................... 100-240V AC
Power Consumption: ................................................. 35 Watts (max.)
Rack Space Required: ................................................ 1U
