FEATURES
Vanco Powered by Wyrestorm HDMI 4x4 HDBaseT (70m/230ft) Matrix is an HD 4 input/4 output switching and
extension system. Have 4 sources displayed simultaneously on any display or have a single source duplicated on
multiple displays, flexibility for the perfect solution. Features HDBaseT (70m/230ft) technology, which allows for
audio, video, IR, and Power over Cable to be transferred over a single Cat5e/6/7 cable up to 230 feet. Simple plug
and play solution that allows each output with the ability to extend HDMI signal up to 230 feet over a single category
5e or 6 cable in conjunction with the Vanco Powered by Wyrestorm HDBaseT (70m/230ft) receiver VPW-280773
(sold separately). Features additional HDMI output per UTP output for flexibility or mirroring capability, able to
be utilized as an 4x8 matrix unit. With an output bandwidth of 6.75 Gbps, the VPW-280754 is capable of full
1080p HD video and HD multi-channel audio distribution with simple control using the front panel or remotely via
IR Receivers at display locations. Also features EDID management system, which allows and encourages device
communication compatibility for seamless integration. Includes RS232 connectivity for firmware updates or third
party integration for control and switching.
Vanco Powered by WyreStorm HDMI® 4 x 4 HDBaseT
(70m/230 ft) Matrix
Part # VPW-280754
y Allows any 4 HDMI input to be distributed
independently and simultaneously over distances
of up to 70m (230ft) to any of the 4 HD output
displays connected to the matrix, regardless of
HDCP encryption, with discrete IR control
y Features Duplicate HDMI ports on each UTP
output for connection to HDMI sources such as an
additional display (effectively doubling the outputs),
AV Receiver, or alternative mode of extension
y Each HDMI port also supports DVI signals
y Each output is able to show any connected source
simultaneously regardless of whether the input
carries HDCP encryption
y HDCP compliant with constant feed to prevent
screen drop-outs
y Reads and copies EDID from connected devices
with additional EDID configuration through
customizable DIP switch settings
y The same robust transmission technology as full
HDBT that is far more resistant to electrostatic
interference than conventional non-HDBT
distribution
y HDMI v1.4 with full 3D compatibility with frame
sequential (Blu-Ray) and interlaced Stereoscoptic
(satellite/cable broadcasts)
y Central RS232 control – fully compatible with all
market leading control systems with full integration
protocols available for AMX, Control 4, Crestron,
Red Eye, Nevo, RTI, Control FX, Savant, Bit Wise
y LAN control – with Control 4 LAN protocols
y Wide range, two way discrete IR control between
source and display and vice versa (38 KHz to 56
KHz frequency)
y 2K resolution (compared to 4k resolution with full
HDBaseT)
y 36bit Deep Color supported
y 6.75 Gbps bandwidth range/signaling rate
y 70m (230 ft) distance range of matrix/extenders
under perfect transmission conditions
y Each Output port can be fed to multiple displays
(cascaded)
y Supports all high definition resolutions up to and
including 1080p and standard video formats
y Choose from 5 switching modes – infrared remote
control, front panel buttons, local IR, IR call-back,
and RS232
y Simple switching remote control included, which
can also be learned into a universal remote
handset to allow the control of multiple devices
from one handset
y 4 x IR 3.5mm mini-jack ports for each output
y Additional infrared extension port for longer IR
connections
y Dimensions: 17.3” W x 1.6” H x 6.6” D
