LPTDX626 VELLEMAN 4
c. Dimming / Switching Setting
STEP 1: Press [DMX] into the DMX status.
STEP 2: Press and hold the [FNC] key for 3 seconds.
STEP 3: Press [FNC] key to select the channel.
STEP 4: Press [▲] or [▼] to select the dimming mode or switching mode.
d. Warm-up Setting
STEP 1: Press [FNC] key.
STEP 2: Press [FNC] key to select the setting channel, e.g. channel 1.
STEP 3: Press [▲] or [▼] key to adjust.
e. Preview Channel Output Status
STEP 1: Enter the DMX status and press the [DMX] key.
STEP 2: Press [▲] or [▼] to preview.
f. Manual Dimming
Push [VR1-VR6] to do the prompt dimming
g. Readout of the Dimming Value and the Internal Temperature
Press [L] to display the dimming value of the DMX channel.
Press [T] to display the internal temperature.
h. DMX Status and DMX address
Press [DMX]. You are in DMX status.
After 10 minutes of inactivity, the DMX activates the DMX status.
AL = all channels
d = dimming mode
S = switching mode
Warm up 6.0% for
channel 1
