OFK1 / OFK2 / OFK3 / OFK4 - OPTIC FIBRE KIT
1. Introduction
To all residents of the European Union
Important environmental information about this product
This symbol on the device or the package indicates that disposal of the device after its lifecycle could harm
the environment.
Do not dispose of the unit (or batteries) as unsorted municipal waste; it should be taken to a specialized
company for recycling.
This device should be returned to your distributor or to a local recycling service.
Respect the local environmental rules.
If in doubt, contact your local waste disposal authorities.
Thank you for buying this OFK optic fibre kit! Read this manual carefully before bringing the device into service.
Make sure that the device was not damaged in transit. If it was, don’t install the device and contact your dealer. If the
power cord is damaged, have it exclusively replaced by an authorised dealer, service centre or qualified person. This
device is for indoor use only; when installing it, make sure it is not exposed to extreme heat, moisture or dust. Avoid
shaking the device or using brute force when installing or operating the device. Use the original packaging if the
device is to be transported. All modifications on this device are forbidden and will void the guarantee. If the device is
installed or operated differently than described in this manual, the product may be damaged and the guarantee
becomes void.
2. Safety Instructions
•
This device falls under protection class I. It is therefore essential that the device be earthed. Have a qualified
person carry out the electric connection.
•
Do not expose your kit to naked flame sources.
•
Do not impede the ventilation by covering the ventilation openings with objects.
•
Make sure to keep a distance of min. 1m between the device and any other object.
3. Installation Instructions
As we have included all required components to form this kit, the installation is very simple. Drill holes, a little larger
than the fibre diameter (see below), in your false ceiling. Insert the fibres into the holes and fix them on the backside
of the ceiling with some silicone glue. For OFK2 & 3: Insert the fibre into the end pieces as deep as possible.
4. Technical specifications
SPECS
OFK1
OFK2
OFK3
OFK4
Colours
blue – white
red, blue, green,
orange, white
multicoloured
Number of fibres
155
100
120
32
Fibre dimension
2m x
∅
0.75mm
2,3,4,5m x
∅
0.75mm
2m x
∅
1.0mm
0.8 - 2.5m x
∅
10mm
Light source
LED
Halogen Lamp MR16
20W/12V
Halogen Lamp MR16
35W/12V
Halogen Lamp MR16
50W/12V
Dimensions (mm)
178 x 80 x 51
180 x 120 x 95
270 x 150 x 130
Weight (kg)
0.65
1.7
3.3
Consumption
4.5W
20W
35W
50W
Power supply
230VAC / 50Hz
The information in this manual is subject to change without prior notice.
