Channel DMX value Description
4-103 Slow strobe to fast strobe
104-107 White
108-207 Fast strobe to slow strobe
208-212 white
213-225 Free strobe, slow
226-138 Free strobe, medium
239-251 Free strobe, fast
252-255 White
3 (Dimming) 0-255 100%
4 (Gobo) 0-3 White
4-7 Gobo 1
8-11 Gobo 2
12-15 Gobo 3
16-19 Gobo 4
20-23 Gobo 5
24-27 Gobo 6
28-31 Gobo 7
32-35 Gobo 8
36-39 Gobo 9
40-43 Gobo 10
44-47 Gobo 11
48-51 Gobo 12
52-55 Gobo 13
56-59 Gobo 14
60-63 Gobo 15
64-67 Gobo 16
68-71 Gobo 17
72-113 Gobo change, fast to slow
114-117 Stop
118-159 Gobo change, slow to fast
160-166 Gobo 2, slow to fast
167-172 Gobo 3, slow to fast
173-179 Gobo 4, slow to fast
180-185 Gobo 5, slow to fast
186-191 Gobo 6, slow to fast
192-198 Gobo 7, slow to fast
199-204 Gobo 8, slow to fast
205-211 Gobo 9, slow to fast
212-217 Gobo 10, slow to fast
218-223 Gobo 11, slow to fast
224-230 Gobo 12, slow to fast
231-236 Gobo 13, slow to fast
237-243 Gobo 14, slow to fast
244-249 Gobo 15, slow to fast
250-255 Gobo 16, slow to fast
5 (Prism) 0-127 White
128-255 Prism
6 (Prism Rotate) 0-20 Angle 0
21-41 Angle 90
42-62 Angle 180
63-83 Angle 270
84-104 Angle 360
